Home/ Products / High-efficiency, low-consumption single-cylinder air-cooled diesel engine KD170F/FE

High-efficiency, low-consumption single-cylinder air-cooled diesel engine KD170F/FE

Name: High-efficiency, low-consumption single-cylinder air-cooled diesel engine KD170F/FE
Rating: 5.0 (50 reviews)

Contact us now to get high-performance single-cylinder air-cooled diesel engine solutions to improve your mechanical power and efficiency!

Shenzhen Jinhaixin Holdings Co., Ltd Shenzhen, China

 

https://shmuker.oss-accelerate.aliyuncs.com/data/oss/687469242fe8040371e8da76/6895ca8c771aae6edad74ae7/20250926170305/Single-Cylinder_Air-Cooled-Diesel-Engine-KD170F-FE.jpeg

Product Parameters

The main parameters

model	KD170F/FE
Power type	Single cylinder, four-stroke, air-cooled, vertical
combustion system	Direct injection
Cylinder diameter*stroke (mm)	70*55
Displacement (L)	0.211
Compression ratio	20 : 1
Rated speed (rpm)	3000 3600
Rated power (kW)	2.5 2.8
Rated power (hp)	3.4 3.8
Start the system	F: Manual start / FE: Electric start
Fuel tank capacity (L)	2.5
Oil capacity (L)	0.75
Fuel consumption (g/kwh)	275 280
Fuel brand	Diesel: 0# (summer), -10# (winter)
Engine oil brand	SAE10W30 (CD grade and above)
Overall dimensions (mm)	332376415
Net weight (kg)	Manual start: 27 / Electric start: 31
Steering (viewed from flywheel)	Clockwise

Product Details

Product Introduction

The engine has a displacement of 0.211L and a rated power of 2.8kW. Its compact and lightweight design allows for both manual start (Type F) and electric start (Type FE) to flexibly meet diverse needs. All key components are sourced from renowned suppliers, with rigorous quality control ensuring high reliability and long service life. The machine operates stably with low vibration and noise, and is easy to maintain, significantly reducing operating costs. This series of diesel engines is particularly suitable for agricultural machinery, outdoor engineering equipment, emergency power supplies, and marine and vehicle power, supporting efficient operations across multiple industries.

Advantages and features

1. Adopting internationally advanced direct injection combustion and high-efficiency fuel injection technology to ensure low fuel consumption and high power;
2. Lightweight and compact design, 0.211L displacement, and rated power of 2.8kW;
3. Available in manual start and electric start models to meet different application requirements;
4. Smooth operation, low vibration, low noise, and improved user comfort;
5. Easy to repair and maintain, reducing long-term use costs

Application Scenario

It is widely used in agricultural machinery, outdoor engineering machinery and equipment, emergency backup power supply, ship-mounted power systems and other industries and markets that require high-efficiency and low-consumption diesel engines. It is the preferred power equipment for machinery manufacturers, equipment rental companies and industry end users.
