High performance, low fuel consumption, single cylinder air-cooled diesel engine KD173F Agricultural portable power system

Contact us now to get a quote on the efficient and durable KD173F single-cylinder air-cooled diesel engine to help you power your machinery!
Shenzhen Jinhaixin Holdings Co., Ltd Shenzhen, China
https://shmuker.oss-accelerate.aliyuncs.com/data/oss/687469242fe8040371e8da76/6895ca8c771aae6edad74ae7/20250926170317/Single-Cylinder_Air-Cooled-Diesel-Engine-KD173F.jpeg

Recommended Products

Product Parameters

The main parameters

model KD173F/FE
Power type Single cylinder, four-stroke, air-cooled, vertical
combustion system Direct injection
Cylinder diameter*stroke (mm) 73*59
Displacement (L) 0.247
Compression ratio 20 : 1
Rated speed (rpm) 3000 3600
Rated power (kW) 3.2 3.6
Rated power (hp) 4.3 4.8
Start the system F: Manual start / FE: Electric start
Fuel tank capacity (L) 2.5
Oil capacity (L) 0.75
Fuel consumption (g/kwh) 275 280
Fuel brand Diesel: 0# (summer), -10# (winter)
Engine oil brand SAE10W30 (CD grade and above)
Overall dimensions (mm) 332*376*415
Net weight (kg) Manual start: 28 / Electric start: 32
Steering (viewed from flywheel) Clockwise
Close
Product Details
Product Introduction
This model features a single-cylinder, four-stroke, air-cooled, vertical design, equipped with an advanced direct-injection combustion system and a new combustion chamber. This ensures efficient fuel combustion, significantly reducing fuel consumption and outperforming comparable gasoline engines. It offers stable power output, with a rated power range of 3.2 to 3.6 kilowatts, strong reserve torque, and excellent overload capacity, making it widely suitable for a variety of applications, including agricultural machinery, outdoor engineering equipment, and emergency power generation. Its precision gear drive and high-efficiency air filter significantly reduce noise and vibration during operation, enhancing operator comfort.
Advantages and features
1. Advanced direct injection combustion system and new combustion chamber design achieve high fuel efficiency and low fuel consumption.
2. Compact and lightweight structure, easy to carry and install, and easy to maintain.
3. Strong power output, rated power 3.2-3.6 kilowatts, with super overload capacity.
4. Advanced gear transmission structure and high-efficiency air filter reduce noise and vibration and improve user comfort.
5. Use high-quality core components to ensure the engine is stable, durable and has a long service life.
6. Multiple technical certifications demonstrate leading diesel engine technology and performance reliability.
7. Applicable to multiple fields, meeting the power needs of agricultural machinery, engineering, emergency power supply, ships and vehicles.
Application Scenario
Widely used in agricultural machinery (such as water pumps and farm tractors), outdoor engineering equipment (such as construction machinery and power units), emergency backup power generation systems, and marine and vehicle power systems. Suitable for overseas customers seeking high-efficiency, low-fuel-consumption, and durable power solutions, including those in the agriculture, construction, transportation, and energy sectors.
